FATEK FBe-40MC - Page 60

FB Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
60
6C)
• 1:1 Connection
• 1:n Connection
Signal name
RDB
SDB
SG
FG
CA4-ADPONL-01
CA3-ADPTRM-01
Display
Display
Terminal block
RDA
SDA
User-created Cable
Shield
External Device
Terminal block
Signal name
D+
D-
FG
TERM
120
(1/4W
)
Terminal
resistance
Ω
Signal name
RDB
SDB
SG
FG
CA4-ADPONL-01
CA3-ADPTRM-01
Display
Display
Terminal block
RDA
SDA
User-created Cable
Shield
External Device
Terminal block
Signal name
D+
D-
FG
TERM
Shield
External Device
Terminal block
Signal name
D+
D-
FG
120
(1/4W
)
Terminal
resistance
Ω
