FB Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
67
6J)
• 1:1 Connection
• 1:n Connection
Number Name Notes
(1)
RJ45 RS-485 Cable (5m) by Pro-face
PFXZLMCBRJR81
External Device
Terminal block
Signal name
D+
D-
FG
120
(1/4W)
Terminal
resistance
Ω
Display
D0
D1
(1)
External Device
Terminal block
Signal name
D+
D-
FG
Shield
External Device
Terminal block
Signal name
D+
D-
FG
220Ω(1/4W
)
Terminal
resistance
220Ω(1/4W)
Terminal
resistance
Display
D0
D1
(1)
User-created Cable
