FATEK FBe-40MC - Page 70

FB Series SIO Driver
GP-Pro EX Device/PLC Connection Manual
70
Cable Diagram 8
Display
(Connection Port)
Cable Remarks
GP3000
*1
(COM1)
AGP-3302B (COM2)
GP-4*01TM (COM1)
ST
*2
(COM2)
LT3000 (COM1)
*1 All GP models except AGP-3302B
*2 All ST models except AST-3211A and AST-3302B
8A
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Connector terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created Cable
Cable length:
1,000m or less
8B User-created Cable
GP3000
*3
(COM2)
*3 All GP models except the GP-3200 Series and AGP-3302B
8C
Online adapter by Pro-face
CA4-ADPONL-01
+
Connector terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created Cable
Cable length:
1,000m or less
8D
Online adapter by Pro-face
CA4-ADPONL-01
+
User-created Cable
IPC
*4
*4 Available only with a COM port that supports RS422/485 (2wire).
) IPC COM Port (page 6)
8E
COM port conversion adapter by Pro-face.
CA3-ADPCOM-01
+
Connector terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created Cable
Cable length:
1,000m or less
8F User-created Cable
GP-4106 (COM1) 8G User-created Cable
Cable length:
1,000m or less
GP-4107 (COM1)
GP-4*03T
*5
(COM2)
GP-4203T (COM1)
8H User-created Cable
Cable length:
1,000m or less
GP4000
*6
(COM2)
GP-4201T (COM1)
SP5000 (COM1/2)
8I
RS-422 Terminal Block Conversion Adapter by Pro-face
PFXZCBADTM1
*7
+
User-created cable
Cable length:
1,000m or less
8B User-created cable
LT-4*01TM (COM1)
LT-Rear Module (COM1) 8J
RJ45 RS-485 Cable (5m) by Pro-face
PFXZLMCBRJR81
Cable length:
200m or less
