FAURE HERMAN 744-082 - Page 49

FAURE-HERMAN
COMPONENT MAINTENANCE MANUAL
744-082 / 744-082-3
28-49-91
PAGE 105
MAR 31/07
. Set LF generator G1 to the frequencies tabulated hereafter and check that
correct values are obtained.
G1 = 0 Hz G1 = 71.1 Hz
RH display 000 250 ± 2
LH display Off Off
(ii) - AS355/365 helicopters selected
. Set resistance boxes BR1 and BR2 to 10 k
. Set LF generator G1 to an amplitude of 100 mV rms and to the frequencies
tabulated hereafter, and check that correct values are obtained.
. Close switch I
5
.
G1 = 0 Hz G1 = G2 = 74 Hz
RH display 000 260 ± 2
LH display 000 260 ± 2
(iii) - AS332 helicopter selected
. Set resistance boxes BR1 and BR2 to 10 k
. Adjust LF generator G1 to an amplitude of 100 mV rms and to the frequencies
tabulated hereafter, and check that correct values are obtained.
. Close switch I
5
.
G1 = 0 Hz G1 = G2 = 82.5 Hz
RH display 000 580 ± 2
LH display 000 580 ± 2
