FAURE HERMAN 744-082 - Mar 31;07

FAURE-HERMAN
COMPONENT MAINTENANCE MANUAL
744-082 / 744-082-3
28-49-91
PAGE 112
MAR 31/07
Lamps
on
Lighting circuit check
Lamps
defective
Replace
lamps
CR402 or CR403
or L402 or L403
defective
(744-082-3)
Replace
defective
component
PC board Z2
defective
Replace PC
board
"TEST-DIM"
control knob
defective
Replace
control knob
PC board Z1
defective
Replace PC
board
RH and LH
displays read
888
No
Yes
No
Test function check
PC board Z3
defective
Replace PC
board
"TEST-DIM"
control knob
defective
Replace
control knob
No
PC board Z2
defective
Replace PC
board
Change in
brightness
Dimming function check
A
