ENGLISH
ENGLISH
Console-700 (art.308-01)
Table of contents
1. General information........................................ 2
2. Operation........................................................ 5
3. Software update.............................................. 8
4. Problem solving.............................................. 8
1. GENERAL INFORMATION
1.1. Purpose
This manual provides the necessary information for the correct use of Console-700 (art.308-01), also called
“product” in this document. We also suggest you keep the manual for the duration of the product’s life.
1.2. Product description
The product consists of a portable console with touchscreen display which enables control of the FC, FS, FW,
FOS and TM series scoreboards. Communication between the console and the scoreboards can be wireless
or through a connection cable.
1.3. Symbols used in the manual
Portions of the text which are of particular importance in regards to the safety or proper use of the product are
indicated by the following symbols.
Warning: risk of danger or injury to persons if instructions or the necessary precautions are not
Caution: situations that could cause damage to your device or other equipment
Note: important information on product use.
1.4. Technical features
Supply: AC Adapter - Battery charger
Input: 90-264V, 47-63Hz, 0.5A (100VAC)
Output: 9.0VDC ± 5%, 0-2.0A, 18W
Temperature of storage: -10 … +70°C (Console)
-20 … +85°C (Power supply - Battery charger)
operating: 0 … 45°C (Console),
0 … 50°C (Power supply - Battery charger)
Relative humidity (without condensation) of storage:
operating:
5 … 95%
10 … 90%
Altitude of storage:
operating:
12000m
200m
Battery: for the power supply: lithium polymer battery, 37Wh (typical),
10Ah (typical), 14-hour average life (level
7 display brightness).
for the internal clock: button type, lithium battery, CR2032,
230mAh, 3V, 7-year average life
expectancy
Size (Width x Height x Depth): 240 x 82 x 168mm
Weight: 1.1kg
Enclosure material: ABS
00308-M01-03-ML - Console-700 User Manual
2 / 44
