Syphon Check Valve
Item # Part # Description Qty
1 400137930 Syphon Check Valve 1
Control Box Assembly (STP-CBS)
Figure 16
Figure 17
Item # Part # Description Qty
1 400575001 Power Switch
(for CBS and CBBS models)
1
2 400574001 Bracket, Power Switch 1
3 400158901 Light Assembly, 120V (CBS) 1
400158902 Light Assembly, 240V (CBBS) 1
4 400215931 Relay, 30A, 120V 1
400215933 Relay, 30A, 240V 1
5 400278005 Terminal Strip 1
6 402410001 Label, Terminal Strip (CBS) 1
402410002 Label, Terminal Strip (CBBS) 1
7 400817901 Cover & Enclosure 1
8 400819001 Wiring Diagram (CBS) 1
400819002 Wiring Diagram (CBBS) 1
Enclosure dimensions: 8.5"H x 5"W x 3"D (215mm x 127mm x 76mm)
