FEC PP-9260 series - S a T a D O C K I N G B O a R

PP-9260 series user’s manual ver 1.0
57
11 RXD2 12 RTS2
13 TXD2 14 CTS2
15 DTR2 16 RI2
17 DIO OUT 0 18 DIO IN 0
19 DIO OUT 1 20 GND
Power Control Connector(JP3)
Pin Signal Pin Signal
1 PWR_PSON 2 GND
+12V Power Connector(PWR1)
Pin Signal Pin Signal
1 GND 2 GND
3 +12V 4 +12V
Power Input Connector(PWR2)
Pin Signal Pin Signal
1 +12V 2 GND
3 +12V 4 GND
USB Connector(USB1)
Pin Signal Pin Signal
1 +5V 2 +5V
3 USBD0+ 4 USBD1+
5 USBD0- 6 USBD1-
7 GND 8 GND
Digital I/O Connector(DRAW1)
Pin Signal Pin Signal
1 GND 2 DI/O Out 0
3 DI/O IN 0 4 +12V
5 DI/O Out 1 6 GND
COM2 Serial Port Connector(COM2)
Pin Signal Pin Signal
1 DCD2 6 DSR2
2 RXD2 7 RTS2
3 TXD2 8 CTS2
4 DTR2 9 +5V/+12V/RI
5 GND 10 N/A
COM4 Serial Port Connector(COM1)
