MSS
TM
Series
© Copyright 2022 Fluid Equipment Development Company | www.fedco-usa.com
- 16 -
4. Install the shipping plug into the motor
adapter seat.
3. Press in on the inlet washer and install the
inlet retaining ring into the groove on the
inlet housing.
NOTES: Make sure the inlet retaining ring is
completely seated in the inlet housing groove.
Figure 19 - Installing Shipping Plug
Figure 18 - Installing Inlet Retaining Ring
Figure 17 - Installing Mechanical and
Stationary Seals
Pump Overhaul Continued
2. Slide the new mechanical shaft seal followed
by the new stationary seal and inlet washer
onto shaft.
To Next Page
