Figure 53 - Removing Cavity Cover
Figure 52 - Removing Discharge Housing
Figure 51 - Removing Discharge Housing Cap
Screws
8. Remove the cavity cover with O-ring.
7. Remove the discharge housing retaining ring
and discharge housing with O-ring from the
end shell.
6. Remove the cap screws, lock washers and
retention clips from the discharge housing.
Pump Overhaul Continued
