MSS
TM
Series
© Copyright 2022 Fluid Equipment Development Company | www.fedco-usa.com
- 57 -
Figure 130 - Final Pump Alignment
NOTES: If a mechanical seal replacement is
necessary, refer to the Mechanical Seal Re-
moval and Mechanical Seal Installation section
of this manual.
32. Refer to the Final Pump Alignment Section
of the MSS Installation Manual for pump re-
alignment procedures.
Figure 129 - Installing the Drain Line
28. Lubricate and install the throttle nipple O-
ring into the discharge housing.
29. Apply thread sealing tape to the throttle
nipple threads and generously lubricate the
non-threaded portion of the throttle nipple.
30. Gently insert throttle nipple using a clock-
wise twisting motion to prevent dislodging
the throttle nipple O-ring.
31. Reconnect the bearing drain line to the
throttle nipple.
Pump Overhaul Continued
