470
+
IN1
-
820
J2
J1
24 V
470
+
IN2
-
820
J4
J3
24 V
470
+
IN3
-
820
J6
J5
24 V
GND
Figure 8: Possible internal power supply for the optocouplers
The input LED for the optocouplers are internally connected to a series resistor of 1290 and are
limited to an input current of max. 20mA. For voltages of less than 10V a part of the series
resistance must be jumpered (J1, J3, J5) accordingly.
Figure 9: Position of the Jumper J1- J9
