Fein FMT 250 - Assembling Gearbox Head

FMT 250; FMT 250Q; FMT 250QSL
7. Assembly
C-SC_CSSM
Version 1.0
2016-11-18
All rights reserved by FEIN, especially in case of industrial rights registration.
FEIN retains all rights of disposal, such as copying and circulation.
Page 24 of 30
Assembling gearbox head
1. Slide gearbox head (1) into motor housing.
2. Screw down gearbox head with the four screws (2) [1.9 ±0.1Nm].
2
1
