FRT: KBM 32 Q
Disassembling tool – Protecting sleeve
The disassembling tool is used for pulling off the protecting sleeve from the SEM – angle.
For pulling off, the disassembling tool should be layed around the protecting sleeve and
moved in to the SEM – angle. By moving in, the snap device will be pushed away and the
protecting sleeve can be moved out together with the disassembling tool.
