Viseo Touch Pad
Fig. 2
KBM80U
Coolant container
Capstan handle
Magnetic foot
Main switch
Clamping lever
Guard protecting against chippings
QuickIN Max
Tool holder
Gear switch
Application tool
Button for cooling lubricant
supply
Button for speed reduction
Stop motor button
Button for starting the drill
motor in clockwise rotation
direction
Button for starting the drill
motor in anticlockwise rota-
tion direction (inch mode)
