2.4.1 Balance tilt axis
Step (a)
· Turn the camera lens upwards.
· Let it go, observe the dropping direction of the camera.
· Loosen the lock screw(red).
· Move the camera.
Status A:
Tip: Slide the 󽗉xed plate slightly in the
direction of the arrow.
Status B:
Tip: Slide the 󽗉xed plate slightly in the
direction of the arrow.
·Move the camera until it can keep upwards, then
tighten the screw.
