FEIYUTECH VB4 - VB4 Gimbal Component Overview

2
1. Overview
[1]
[8]
[6]
[5]
[7]
[3]
[2]
[4]
[18]
[19]
[21]
[22]
[23]
[24]
[10][9]
[12]
[13]
[14]
[16]
[11]
[17]
[15]
[25]
[20]
[1] Roll axis
[2] Cross arm
[3] Tilt axis
[4] Vertical arm
[5] Pan axis
[6] Trigger button
(custom functions in App)
[7] USB-C port for accessories
[8] Limitation
[9] Status/Battery indicator
[10] Bluetooth indicator
[11] Follow status indicator
[12] Joystick
[13] Knob
[14] Knob function switching button
[15] Album button
[16] Shutter button
[17] M button
(custom functions in App)
[18] Magnetizable nameplate
[19] Smartphone holder
[20] Extendable rod
[21] Power button
[22] USB-C port
[23] Handle (built-in battery)
[24] 1/4 inch thread hole
[25] Tripod
* This product dose NOT include smartphone.
