Fender Bullet 15 DSP Service Manual

BULLET® 15 DSP
(This is the model name for warranty claims)
2
June, 2002
IMPORTANT NOTICE
Copyright © 2002 FMIC. All rights reserved. All
information contained herein is CONFIDENTIAL
and PROPRIETARY and is the property of Fender®
Musical Instruments Corporation. It is not to be
sold or assigned to another party and is disclosed
solely for use by Fender Authorized Service Cen-
ters for purposes of product service and
maintenance. All information is not to be disclosed
to others without the expressed permission of
Fender® Musical Instruments Corporation. All
specifications are subject to change without notice.
This information and any copies produced elec-
tronically or otherwise must be surrendered upon
demand of Fender Musical Instruments Corpora-
tion.
Parts marked with two asterisks (
**
) indicate the re-
quired use of that specific part. This is necessary
for RELIABILITY and SAFETY requirements.
DO NOT USE A SUBSTITUTE!
PARTS LIST CODES
The description codes used in the itemized Parts Lists are defined below:
CAPACITOR CODES
CAP AE = Aluminum Electrolytic
CAP CA = Ceramic Axial
CAP CD = Ceramic Disk
CAP MPF = Metalized Polyester Film
CAP MY = Mylar
CAP PFF = Polyester Film/Foil
RESISTOR CODES
RES CC = Carbon Comp
RES CF = Carbon Film
RES FP = Flame Proof
RES MF = Metal Film
RES WW = Wire Wound
HARDWARE CODES
BLX = Black Oxide
CR = Chrome Plated
HWH = Hex Washer Head
M = Machine Screw
NI = Nickel Plated
OHP = Oval Head Phillips
PB = Particle Board
PHP = Pan Head Phillips
PHPS = Pan Head Phillips Sems
SMA = Sheet Metal "A" Point
SMB = Sheet Metal "B" Point
SS = Stainless Steel
TF = Thread Forming
ZI = Zinc Plated

Fender Bullet 15 DSP Specifications

General

Brand	Fender
Model	Bullet 15 DSP
Category	Amplifier
Language	English
