BULLET® 15 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
7
PARTS LIST: MAIN – PCB ASSEMBLY (continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
3
*
LED, RED LONG LEAD LUMEX D1-2 D16
1
*
SPACER LED .5x.1 BRN @ D16
1
*
RES CF 1/2W 1.5k 5% R64
1
*
RES CF 1/2W 5.6 ohm 5% R44
2
*
RES CF 1/4W 27k 5% R50-51
3
*
RES CF 1/4W 100k 5% R38 R46-47
6
*
RES CF 1/4W 10k 5% R8 R37 R61 R67 R71 R73
3
*
RES CF 1/4W 15k 5% R1 R6 R32
1
*
RES CF 1/4W 180k 5% R36
4
*
RES CF 1/4W 1k 5% R7 R26 R54-55
2
*
RES CF 1/4W 1M ohm 5% R66 R76
4
*
RES CF 1/4W 2.2k 5% R12 R59 R69-70
5
*
RES CF 1/4W 220k 5% R10 R14-15 R23 R25
4
*
RES CF 1/4W 22k 5% R16-17 R31 R77
4
*
RES CF 1/4W 30k 5% R52-53 R56-57
5
*
RES CF 1/4W 3.3k 5% R19 R21 R49 R74-75
1
*
RES CF 1/4W 4.7k 5% R68
2
*
RES CF 1/4W 470k 5% R22 R48
5
*
RES CF 1/4W 47k 5% R11 R27-30
1
*
RES CF 1/4W 5.1Kohm 5% R5
2
*
RES CF 1/4W 510Kohm 5% R2 R4
3
*
RES CF 1/4W 6.8k 5% R3 R58 R72
1
*
RES CF 1/4W 75k 5% R60
1
*
RES CF 1/4W 8.2k 5% R18
1
*
RES CF 1/4W 82k 5% R9
2
*
RES CF 1/4W 820ohm 5% R41 R45
1
*
RES CF 1/4W 120k 5% R78
2
*
RES FILM 1W .68 ohm 5% R42-43
2
*
RES FILM 1W 120 ohm 5% LL R39-40
2
*
RES FILM 1W 220ohm 5% R62-63
2
*
SCRW M 4-40x3/8 PHP BLX @ U5 U7
2
*
SCRW TF 6-32x3/8 PHP ZI @ HEATSINK
2
*
NUT HEX 4-40 EX LOCK @ U5 U7
1
*
INSULATOR MICA TO-220 @ U5
1
*
SWITCH PUSH SLFLK SHORT STROKE S1
1
*
BUTTON PUSH OFF WHITE @S1
1
* **PCB WIRE SET, BULLET 15 DSP
1
*
WSHR SHLDR NYL 1/8x1/4 @ U5
2
*
XSTR N-CH JFET J111 TO-92 Q1-2
2
***FUSE CLIP PCB 5MM
F1
42
*
JUMPER WIRE 22 GA W1-21 W23-43
