INTERNAL TRIM POTENTIOMETERS (ACCESSIBLE BY
REMOVING COVER)
MIDRANGE trim pot is an EQ cut/boost control and is flat when set in
the center.
FILTER trim pot is a low-pass filter that helps remove excess high-
frequency energy or “fizz” (around 4kHz and higher) from
brighter-sounding amplifiers.
Remove cover using a flat-head screwdriver. Adjust trim pots using a
Phillips-head screwdriver.
MIDRANGE TRIM POT
FILTER TRIM POT
9V BATTERY
(NOT INCLUDED)
