PASSPORT
®
PD-150 PLUS
(This is the model name for warranty claims)
3
SPECIFICATIONS
Model Name: PASSPORT PD-150 PLUS
Release Number: PR688
Part Number: (120V, 60Hz) US: 069-3005-000
(120V, 60 Hz) DS: 069-3005-900
(240V, 50 Hz) AUS: 069-3005-930
(230V, 50 Hz) UK: 069-3005-940
(230V, 50 Hz) EUR: 069-3005-960
(100V, 50 Hz) JPN: 069-3005-970
Frequency Response: 50 Hz to 20 kHz ± 1 dB (at speaker output)
30 Hz to 20 kHz ± 1 dB (at send output)
Distortion: < 0.5%, 20 Hz to 20 kHz (at speaker output)
< 0.1%, 20 Hz to 20 kHz (at send output)
Signal to Noise Ratio: > 90 dB, “A” WTD
Power Output: 150W (75W/ch @ 8
Ω per channel)
Input Impedance:
(Channels 1-2 XLR and 1/4”) “Mic” switch position: 2 k
Ω
“Line” switch position: 66 k
Ω
(Phono and Stereo Channel 1/4”) 78 k
Ω
Max. Input Level: Mic: -11 dBu
Line: 20 dBu
Stereo: 26 dBu
Return Input Impedance: 47k
Ω
Fuse type: T3.15AL, 250V
Passport System: Width: 610 mm (24 in.)
Height: 541 mm (18 in.)
Depth: 254 mm (10 in.)
Weight: 14.97 kgs (33 lbs)
Speakers: Width: 245 mm (9.65 in.)
Height: 439 mm (17.5 in.)
Depth: 241 mm (9.5 in.)
Weight: 4.08 kgs (9.0 lbs)
Power Tower: Width: 245 mm (9.65 in.)
Height: 451 mm (18 in.)
Depth: 178 mm (7 in.)
Weight: 6.80 kgs (15.00 lbs)
Tower Footprint: 241 x 298 mm (9.5 x 11.75 in.)
Microphone: Dynamic Cardioid, balanced
Microphone Cable: XL -Male to XL-Female, 6 m (20 feet)
Speaker Cables: 1/4 in. to 1/4 in., 9 m (27 feet)
0 dBu is referenced to 0.775 volts rms
Product specifications are subject to change without notice
