PASSPORT
®
PD-150 PLUS
(This is the model name for warranty claims)
5
STEP G: PD150+ LCD KEY PCB
G1. Unscrew six screws from the LCD KEY PCB.
G2. Detach all connectors.
G3. The procedure is completed.
STEP H: PD150+ CD SERVO PCB
H1. First complete STEP D.
H2. Unscrew three screws from the SMPS at the
front panel.
H3. Unscrew two screws from the CD mechanism
at the back.
H4. Detach all wiring from the SMPS cabinet.
H5. Unscrew four M2 machine screws from the
CD SERVO PCB assembly
H6. Detach/De-solder all wiring and connectors
from the CD SERVO PCB assembly.
H7. The procedure is completed.
STEP I: Output Jack PCB
I1. Remove the two M9 nuts and washers on the
Output Jack PCB assembly.
