PASSPORT
®
PD-150 PLUS
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
9
.PARTS LIST: CD SERVO - PCB ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 REF *LED SC 2.9X5.4XL0.5 IR 950NM HALF AN-
GEL+/-10DEG
LED1-2
1 REF *PCB CD/KEY 4/L 10Z FR4 EFPAPD150+05CS17
1 REF *RCF 1/4W 4.7R 5% ATS R549
1 REF *RMG 1/16W 100R 1% 0603 R555
9 REF *RMG 1/16W 10K 1% 0603 HK RESIS-
TOR/SAMSUNG
R506 R517 R521 R524 R534 R536 R538
R540-541
1 REF *RMG 1/16W 10R 5% 0603 HK RESIS-
TOR/SAMSUNG
R501
1 REF *RMG 1/16W 15K 1% 0603/1608 R518
3 REF *RMG 1/16W 1K 1% 0603/1608 R507 R535 R537
4 REF *RMG 1/16W 2.2K 1% 0603/1608 R420 R446 R447 R505
1 REF *RMG 1/16W 2.2M 5% 0603 R519
4 REF *RMG 1/16W 220R 1% 0603/1608 R401 R404 R407 R516
4 REF *RMG 1/16W 22K 1% 0603 HK RESIS-
TOR/SAMSUNG
R502 R504 R523 R542
1 REF *RMG 1/16W 470K 1% 0603 R520
1 REF *RMG 1/16W 47K 1% 0603 HK RESISTOR/ SAM-
SUNG
R503
1 REF *RMG 1/16W 5.6K 1% 0603/1608 R522
1 REF *RMG 1/16W 820R 1% 0603 HK RESIS-
TOR/SAMSUNG
R515
4 REF *RMG 1/16W 82K 5% 0603/1608 R510-511 R513-514
1 REF *RMG 1/16W 91R 5% 0603/1608 R405
1 REF *SW DETECTOR PUSH SPST DTS-03-SMT LUP
FUNG
SW401
1 REF *TR 2SA1015-GR(TE2/F/T) RLT TOSHIBA Q401
1 REF *TR PNP 2SB1457 TO-92 RL Q402
2 REF *WAFER 4P P2.0 90DEG JAPAN CN405 CN409
1 REF *X'TAL 16.9344MHZ +/-30PPM AT-51 X401
.PARTS LIST: LCD DISPLAY - PCB ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0074494000 PCB ASSY LCD DISPLAY CONTROL
5 REF *CC 16V 0.1U 10% 0603/1608 1X2 C701-704 C709
1 REF *CC 50V 2.2U 10% 1206 X7R MURATA C708
1 REF *CONNECTOR FFC 20P P1.0 STRAIGHT F J701
1 REF *CRYSTAL 32.768KHZ 2X6 +/-20PPM 6PF Y701
2 REF *CTC 0/60 22pF 5% 0603 0.8X1.6 C706-707
