Fender Princeton Chorus DSP Service Manual

PRINCETON CHORUS DSP
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
23 0006260001 DIODE 1N4448 SIGNAL D1-12 D17-18 D21-24 D26-28 D30-31
7 0064089001 DIODE 1N4003 D13-16 D29 D36-37
4 0020534000 DIODE 1N5402 RECTIFIER 200V C&F D32-35
2 0031635001 DIODE ZEN 1N5240B 10V 5% D19 D25
1 0041074000 ENCODER 16-POS 4-BIT BINARY S5
1 0026000001 FSTN TAB MALE.187x.032 PCB MT P12 (ass’y P/N 0055580000 domestic)
3 0026000001 FSTN TAB MALE.187x.032 PCB MT P12 P15-16 (ass’y P/N 0055581000
export)
8 0025802000 FSTN TAB MALE .250x.032 PCB MT P1-4 P6-8,P10
(ass’y P/N 0055580000domestic)
11 0025802000 FSTN TAB MALE .250x.032 PCB MT P1-5 P7 P9-11 P13-14
(ass’y P/N 0055581000
export)
2 0051094003 FUSE CLIP PCB 5mm (EXPT) @F1 (ass’y P/N 0055580000
domestic)
6 0051094003 FUSE CLIP PCB 5mm (EXPT) @F1-3 (ass’y P/N 0055581000
export)
1 0027421000 HDR .1 CTR 12 CKT SQ PIN P17
6 0031611000 IC OP-AMP DUAL PC4560 U4-7 U10-11
3 0016795000 IC OP-AMP DUAL TL072 U1-3
1 0041261000 IC VOLT REF LM4040DIZ-10.0 U12
2 0054377000 IC POWER AMP TDA1514A 40W U8-9
1 0054648000 HEATSINK PLATE DUAL TDA1514A @U8-9
2 0054378000 INSULATOR MICA 9 PIN SIP @U8-9
4 0027638000 SCRW TF 4-40x3/8 HWHS ZI .1"HD @U8-9
2 0032908000 SCRW TF 6-32x3/8 PHP ZI PCB to HEATSINK PLATE
1 0041812000 IC REGULATOR +5V MC7805CT U13
1 0013562000 IC REGULATOR +15V MC7815CT U14
1 0013564000 IC REGULATOR -15V MC7915CT U15
3 0050849000 HEATSINK PCB LEVEL 576012U @U13-15
3 0039420000 SCRW M 4-40X3/8 PHP SS SEMS @U13-15
3 0097360000 NUT HEX 4-40 EX LOCK @U13-15
1 0051658000 JACK MONO R/A J7
6 0053450000 JACK STEREO R/A J1-6
1 0048332000 LED RED PNL MT 7" D38
1 0049948000 LED RED LONG LEAD LUMEX D20
1 0036178000 SPACER LED .5x.1 BRN A6192-1 @D20
1 0028036000 LED 21L994 OPTO-ISOLATOR OP1
3 0024947001 RES CF 1/4W 47ohm 5% R72 R151-152
1 0028015001 RES CF 1/4W 130ohm 5% R37
2 0024955001 RES CF 1/4W 180ohm 5% R70 R150
1 0024961001 RES CF 1/4W 470ohm 5% R8
10 0024965001 RES CF 1/4W 1k 5% R20 R51-54 R91-94 R122
1 0028842001 RES CF 1/4W 1.1k 5% R11
1 0024969001 RES CF 1/4W 1.5k 5% R127
2 0024973001 RES CF 1/4W 3.3k 5% R18 R36
4 0024975001 RES CF 1/4W 3.9k 5% R101-102 R109-110
1 0028034001 RES CF 1/4W 5.1k 5% R5
PRINCETON CHORUS DSP
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4 0024979001 RES CF 1/4W 6.8k 5% R6 R97-98 R136
4 0025942001 RES CF 1/4W 7.5k 5% R15 R31-32 R73
6 0024981001 RES CF 1/4W 10k 5% R45-48 R139 R141
1 0029002001 RES CF 1/4W 11k 5% R14
4 0024983001 RES CF 1/4W 12k 5% R74 R88 R95-96
5 0024985001 RES CF 1/4W 15k 5% R7 R75-76 R123 R137
13 0024987001 RES CF 1/4W 22k 5% R12-13 R25-26 R28 R39 R57-60 R65-66
R142
2 0028863001 RES CF 1/4W 24k 5% R16 R87
7 0024988001 RES CF 1/4W 27k 5% R35 R77-78 R103-106
1 0024991001 RES CF 1/4W 39k 5% R38
7 0024993001 RES CF 1/4W 47k 5% R34 R81-86
1 0024994001 RES CF 1/4W 56k 5% R10
3 0024995001 RES CF 1/4W 68k 5% R1-2 R27
14 0024997001 RES CF 1/4W 100k 5% R49-50 R55-56 R63-64 R79-80 R89-90 R132
+R138 R140 R144
1 0025059001 RES CF 1/4W 220k 5% R43
2 0025061001 RES CF 1/4W 330k 5% R117-118
6 0025065001 RES CF 1/4W 470k 5% R44 R67-68 R120 R126 R135
2 0028018001 RES CF 1/4W 510k 5% R3-4
3 0025067001 RES CF 1/4W 680k 5% R99-100 R143
2 0025068001 RES CF 1/4W 820k 5% R29 R134
5 0025069001 RES CF 1/4W 1M 5% R21 R23-24 R121 R125
2 0025079001 RES CF 1/4W 4.7M 5% R145-146
1 0025084001 RES CF 1/4W 10M 5% R17
1 0016953001 RES MF 1/4W 1.78k 1% R71
2 0015581001 RES MF 1/4W 9.53k 1% R69 R131
1 0040772001 RES MF 1/4W 15.0k 1% R130
1 0017191001 RES MF 1/4W 36.5k 1% R133
1 0031820001 RES MF 1/4W 49.9k 1% R129
1 0016979001 RES MF 1/4W 215k 1% R128
2 0030737001 RES CF 1/2W 5.6ohm 5% R111-112
1 0028861001 RES CF 1/2W 3.3k 5% R124
3 0027344001 RES FILM 1W 270ohm 5% R147-149
1 0029722001 RES FILM 1W 1k 5% R119
2 0027628001 RES MOX 2W 47ohm 5% R113-114
2 0028028000 RES WW BT 5W .47 ohm 5% R107-108
2 0029670000 RES WW BT 5W 150 ohm10% R115-116
4 0028091000 SWITCH PUSH SLFLK SHORT STROKE S1-4
4 0048451000 BUTTON PUSH OFF-WHITE @S1-4
1 0028503000 THERMISTOR 10 ohm 5A C60-11 RT1
3
