Fender Princeton Chorus DSP Service Manual

PRINCETON CHORUS DSP
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
5 0014689003 XSTR N-CH JFET J111 TO-92 Q1-3 Q8-9
1 0016739003 XSTR NPN 2N4401 TO-92 Q7
3 0016742003 XSTR PNP 2N4403 TO-92 Q4-6
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0055584000 CHASSIS PRINCETON CHORUS DSP
1 0055580000 PCB ASSY PRNCTN CHRS DSP DOM
1 0055581000 PCB ASSY PRNCTN CHRS DSP EXP
1 0048384000 FUSE 20mmX5mm F2A 250V (100V/120V)
1 0013112000 FUSE TD 20mmx5mm 250v 1A (230V/240V)
2 0013681000 FUSE TD 20mmx5mm 250v 5A (Export only)
1 0025935000 SWITCH DPST .187 TAB (DOM) (100V/120V)
1 0039287000 SWITCH DPST .187 TAB GLOBAL (230V/240V)
5 0051404000 STANDOFF NYLON BLK .375
13 0026402000 KNOB POINTER BLACK
1 0029648000 XFMR PWR 120V PRINC (Domestic only)
1 0029649000 XFMR PWR EXPORT PRCR/CHRLD50
1 0028560000 END BELL XFMR 85W
4 0028591000 NUT ACORN 8-32
4 0030007000 WSHR LCK INTL 8x.330x.02 ZI
1 0038900000 SCRW TF 6-32X1/4 PHP ZI
1 0055582000 PANEL FRNT PRNCTN CHRS DSP
1 0055583000 PANEL REAR PRNCTN CHRS DSP
1 0028499000 HEATSINK BAR
3 0028500000 SCRW TF 8-32x3/4 HWH SLTD ZI
2 0021709000 BUSHING SR .437x.062x13/32 BLK
1 0054642000 CONNECTOR IEC SNAP-IN
1 0055590008 PCB ASSY DSP PRNCTN CHRS DSP
1 0027288000 LENS LED RED
PRINCETON CHORUS DSP
PARTS LIST
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4 0019275000 INSERT GLIDE CUSHION 1.27 DIA
4 0019276000 GLIDE CAB 1.24 X .335
2 0019279000 HANDLE CAP 2 HOLE NICKEL
1 0027846000 HANDLE 9.25" NO LOGO
1 0032524000 INSERT HANDLE
4 0026566000 CORNER 2 HOLE W/TAB NI
2 0026568000 CORNER 3 HOLE NI
12 0021972000 NUT T 10-32 X 3/4 STR 3 PRNG BLX
4 0022244000 SCRW M 10-32 X 1-1/8 OHP NI
10 0026571000 SCRW SMAB 8 X 5/8 THP NI
4 0026625000 SCRW WOOD 8 X 1 FH
1.06 0026570000 TOLEX BLACK
.6 0037788000 CLOTH GRILLE BLACK/SILVER
FOOTSWITCH ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0028109000 HSG END CUP LEFT FTSW
1 0028141000 HSG FTSW 3 BUTTON
1 0028143000 HSG END CUP RIGHT FTSW
1 0028895000 CABLE ASSY FTSW RT ANG 12'
1 0031647000 NUT HEX 12mmx1mm NI
8 0028684000 SCRW SMB 6x3/8 PH PHS BLX
3 0031899000 WSHR NYL .485x.775x.150 TK
1 0055594000 PLATE FTSW 3 BTN PRNCTN CH DSP
1 0055593000 PCB ASSY FTSW 3 BTN PRNCTN DSP
FOOTSWITCH PCB ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
3 0006260001 DIODE 1N4448
3 0028039000 LED RED 5x5mm SLB-55VR3
3 0028714000 SWITCH PUSH SPDT
1 0031017000 DIODE ZEN 1N5223B 2.7V 5%
3 0034921000 SPACER RND NYL .147x.250x.780
1 0037036000 JACK PCB MONO CA(099-0912-000)
1 0053898000 PCB FAB FTSW 3 BTN SUNN BASS
