Fender Prosonic User Manual

G. TREBLE - Adjusts the overall brightness of the amplifier.
H. BASS - Adjusts the low frequencies of the amplifier.
I. MID - Adjusts the midrange frequencies of the amplifier.
J. MASTER- Controls the loudness of the DRIVE channel ONLY.
K. REVERB- (Combo only) Controls the strength of the Reverb (both channels). This effect may be selected
on or off via the footswitch.
L. PILOT JEWEL - Illuminated when the Prosonic is receiving power. If the lamp burns out, unplug the
amplifier, unscrew the green jewel and replace the lamp with a type T47 light bulb.
I J K
L

Fender Prosonic Specifications

General

Type	Tube Amplifier
Power Output	60 Watts
Reverb	Spring Reverb
Output Power	60 Watts
Rectifier	Solid State
Effects	Reverb
Preamp Tubes	5 x 12AX7
Effects Loop	Yes
Channels	2
Controls	Volume, Treble, Bass, Reverb
Outputs	Speaker Output
Footswitch	Channel
Power Tubes	2x 6L6GC
Speaker Outputs	2 x 1/4"
Dimensions	10.5" (26.7 cm)
Tubes	6L6GC (Power), 12AX7 (Preamp)
