Fender ROC PRO 1000 - Specifications; Parts List; Printed Circuit Board Assembly

SPECIFICATIONS
Type PR 209
Input impedance: >1M ohm
Nominal level: 100mV
Power output: 69 Watts R.M.S. into 8 ohms @ 5% THD
94 Watts R.M.S. into 4 ohms @ 5% THD
Effects loop: Nominal Level; Selectable +4, -7, -16 dBV
Output Impedance: 1.2k ohms
Input Impedance: 100k ohms
Dimensions:
Combo Head
Height: 17.5 inches (44.5 cm) 8.5 inches (21.6cm)
Width: 22.5 inches (56.8 cm) 22.5 inches (56.8 cm)
Depth: 10.25 inches (25.9 cm) 9.5 inches (24.1 cm)
Weight: 41 lbs. (18.6 kg) 25 lbs. (11.4 kg)
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 040260 PCB ASSY PERFORMER 1000 (STUFFED)
1 031910 BREAKER THERMAL 15A 155/195DEG TH1
3 028104 BUTTON PUSH SWITCH BLACK S1-3
1 028577 CABLE ASSY REVERB 30" P1-4
2 029719 CABLE FLAT 5 CKT 10" P9,10
1 037943 CAP AE RDL .33µF 50V 20% C52
5 038689 CAP AE AX .47µF 100V 20% C20,22,39,40,44
1 038690 CAP AE AX 1.0µF 100V 20% C1
3 026517 CAP AE AX 2.2µF 50V 20% C9,50,76
1 028459 CAP AE RDL 2.2µF 50V 20% C48
1 028460 CAP AE RDL 4.7µF 50V 20% C51
1 038692 CAP AE AX 10µF 35V 20% C62
6 025960 CAP AE AX 22µF 16V 20% C10,12,38,42,55,61
1 028465 CAP AE RDL 22µF 25V 20% C56
4 028471 CAP AE RDL 47µF 50V 20% C53,54,73,74
2 025787 CAP MINI AE 100µF 16V NP C57,58
2 031756 CAP AE 4700µF 50V 20% C71,72
1 038873 CAP CA 22pF 100V 5% C47
1 039256 CAP CA 68pF 100V 5% C37
3 038699 CAP CA 100pF 100V 5% C8,23,45
1 038700 CAP CA 390pF 50V 5% C4
4 038701 CAP CA 470pF 50V 5% C18,19,31,49
1 038874 CAP CA 560pF 50V 5% C27
3 039263 CAP CA 1000pF 100V 5% C7,26,75
1 039264 CAP CA 1500pF 100V 5% C33
1 039265 CAP CA 2200pF 100V 5% C43
1 039266 CAP CA 3300pF 100V 5% C11
2 039268 CAP CA 4700pF 50V 5% C2,3
3 027278 CAP MPF .1µF 63V 10% C32,59,60
3 027281 CAP MPF .22µF 63V C6,16,35
4 027286 CAP MPF .47µF 63V C5,17,34,63
1 036234 CAP PFF RDL .015µF 100V 10% C46
6 033591 CAP PFF RDL .033µF 100V 10% C13,14,15,30,41,64
10 033592 CAP PFF RDL .047µF 100V 10% C24,25,28,29,65-70
1 027937 CONTROL SNAPIN 2K 15A TAPER R14 (MID)
3 027940 CONTROL SNAPIN 50K 15A TAPER R12,13,61 (BASS, TREBLE/CH1)
5 027941 CONTROL SNAPIN 50K B TAPER R22,54,60,76,85 (VOLUME/CH1,BODY,
TREBLE/CH2,EFFECTS MIX,REVERB)
2 027943 CONTROL SNAPIN 50K 30C TAPER R30,31 (GAIN 1,2)
1 027947 CONTROL SNAPIN 100K 30C TAPER R57 (VOLUME/CH2)
