PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART # DESCRIPTION REFERENCE DESIGNATION
42 006260 DIODE 1N4448 SIGNAL BENT CR1-9,11-24,29-32,35,36,39-42,45-47,
50,51,58-60,62
2 064089 DIODE 1N4003 CR37,38
4 028776
*
DIODE BIAS BYV26D LEAD FORMED CR25-28
4 029045 DIODE 6A 400V 6A4 LEAD FORMED CR52-55
1 041261
*
DIODE LM4040DCZ-10 TO-92 CR49
2 027327 DIODE ZENER 1N5234B 6.2V 5% CR33,34
1 027329 DIODE ZENER 1N5228B 3.9V 5% CR44
2 028119 DIODE ZENER 1N5353B 5W 16V 5% CR56,57
1 031017 DIODE ZENER 1N5223B 2.7V 5% CR43
1 031019 DIODE ZENER 1N5245B 15V 5% CR48
2 041320 DIODE ZENER 1N5341B 6.2V 5% CR10,63
12 025802 FSTN TAB MALE .250X.032 PCB MT CP1-5,7-11,13,14
2 026000 FSTN TAB MALE PCB MT .187X.032 CP6,12
2 025996 FUSE CLIP PCB .250 & 5MM FUSE XF1
1 039982 FUSE QA 1-1/4X1/4 250V 4AMP F1 (100V/120V ONLY)
1 020794 FUSE QA 20mmX5mm 250V 2AMP F1 (220V/230V/240V 0NLY)
1 031725 HEATSINK PLATE M-80 (TRANSISTOR MOUNTING)
9 016795 IC DUAL OP AMP TL072 U1-6,8-10
1 028047 IC OP AMP MC1436 U7
4 040903 INSULATOR MICA TO-218 (@ Q11,12,13,14)
1 011028 JACK 1/4 13E (EXTERNAL SPEAKER JACK)
3 031570 JACK PHONE PCB STEREO PREMIUM J1,3,5 (INPUT, RETURN, LINE OUT)
2 037036 JACK PHONE PCB MONO CA PREMIUM J2,4 (SEND, FOOTSWITCH)
47 020888 JUMPER WIRE 22GA .5X.175 W1-47
1 040270 LED RED 5MM ROUND PC MT LD2
1 040271 LED RED/YELLOW LD1
1 040259 PCB FAB PERFORMER 1000 (RAW BOARD)
1 025818 RES CF 1/4W 4.7Ω 5% R163
1 024947 RES CF 1/4W 47Ω 5% R81
2 024956 RES CF 1/4W 220Ω 5% R44,45
2 024957 RES CF 1/4W 270Ω 5% R107,110
2 029604 RES CF 1/4W 300Ω 5% R15,143
2 029451 RES CF 1/4W 430Ω 5% R62,67
2 029609 RES CF 1/4W 910Ω 5% R139,156
9 024965 RES CF 1/4W 1K 5% R24,46,52,56,71,105,106,111,129
1 028842 RES CF 1/4W 1.1K 5% R68
1 024967 RES CF 1/4W 1.2K 5% R66
2 024969 RES CF 1/4W 1.5K 5% R43,83
PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 029453 RES CF 1/4W 1.6K 5% R47
4 024971 RES CF 1/4W 2.2K 5% R21,58,103,104
2 024972 RES CF 1/4W 2.7K 5% R49,69
5 024973 RES CF 1/4W 3.3K 5% R29,32,34,42,50
2 024975 RES CF 1/4W 3.9K 5% R92,117
1 024977 RES CF 1/4W 4.7K 5% R80
2 028034 RES CF 1/4W 5.1K 5% R7,73
1 024979 RES CF 1/4W 6.8K 5% R9
2 025942 RES CF 1/4W 7.5K 5% R20,28
1 024980 RES CF 1/4W 8.2K 5% R27
8 024981 RES CF 1/4W 10K 5% R2,82,128,131,132,141,153,154
1 029539 RES CF 1/4W 13K 5% R75
2 024985 RES CF 1/4W 15K 5% R4,6
2 029006 RES CF 1/4W 20K 5% R108,109
6 024987 RES CF 1/4W 22K 5% R11,16,25,26,51,59
2 024988 RES CF 1/4W 27K 5% R93,95
11 024993 RES CF 1/4W 47K 5% R53,55,89-91,149,150,157,158,164,165
1 028990 RES CF 1/4W 51K 5% R74
1 026507 RES CF 1/4W 62K 5% R167
6 024997 RES CF 1/4W 100K 5% R36,65,72,77,78,122
3 025058 RES CF 1/4W 180K 5% R17,23,35
5 025059 RES CF 1/4W 220K 5% R19,63,79,84,166
1 025063 RES CF 1/4W 390K 5% R171
5 025065 RES CF 1/4W 470K 5% R64,88,124,168,169
2 028018 RES CF 1/4W 510K 5% R5,8
2 025067 RES CF 1/4W 680K 5% R94,125
1 025068 RES CF 1/4W 820K 5% R142
12 025069 RES CF 1/4W 1M 5% R1,3,48,86,87,126,130,133,134
136,137,152
3 025073 RES CF 1/4W 1.5M 5% R148,151,159
3 025084 RES CF 1/4W 10M 5% R10,18,123
1 041259
*
RES MF 1/4W 73.2K 1% R145
1 041260
*
RES MF 1/4W 80.6K 1% R144
1 036202
*
RES MF 1/4W 118K 1% R146
1 016985
*
RES MF 1/4W 562K 1% R140
1 040714
*
RES MF 1/4W 768K 1% R147
3 031767 RES CF 1/2W 15Ω 5% R70,120,121
1 026549 RES CF 1/2W 1.5K 5% R162
1 037169 RES CF 1/2W 1.8K 5% R138
2 026493 RES CF 1/2W 2.7K 5% R118,155
2 037354 RES CF 1W 4.7K 5% R101,102
