PARTS LIST
PRINTED CIRCUIT BOARD ASSEMBLY
CONTINUED
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 028029 RES FILM 1W 1.5K 5% R99,100
2 028030 RES FILM 1W 680Ω 5% R97,98
1 028045 RES FILM 1W 220Ω 5% R96
1 029722 RES FILM 1W 1K 5% R127
1 028021 RES FILM 2W 470Ω 5% R119
4 028028 RES WW BT 5W .47Ω 10% R112-115
2 037845 RES WW BT 5W 47Ω 10% R160,161
3 041256 RES WW 5W 470Ω 10% R37-39
1 031703 RES WW BT 10W .22Ω 10% R116
2 041276 RES WW BT 10W 100Ω 10% R172,173
4 027638 SCRW TF 4-40X3/8 HWH ZI (@ Q11-14)
6 032908 SCRW TF 6-32X3/8 PHP ZI (PCB TO HEATSINK & TH1)
1 029167 SOCKET TUBE 9 PIN PCB MOUNT XV1
3 028091 SWITCH PUSH SLFLK SHORT STROKE S1-3
1 038652 SWITCH SLIDE 4P3T S4
1 028503
*
THERMISTOR 10 OHM 5AMP C60-11 TH1
1 013341 TUBE VACCUUM 7025/12XAX7 V1
.104 016420 TUBING SHRINK 1-1/2 BLK (@ V1)
4 028169 WSHR SHLDR NYL 5/32X1/4 Q11-14
2 041465 XSTR FET J113 Q1,2
6 014689 XSTR N-CH JFET J111 TO-92 Q3-8
3 016739 XSTR NPN 2N4401 TO-92 Q9,15,16
1 016742 XSTR PNP 2N4403 TO-92 Q10
2 028114
*
XSTR NPN TIP142 TO-218AC Q11,12
2 028115
*
XSTR PNP TIP147 TO-218AC Q13,14
PARTS LIST
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 050328 CHS ASSY ROC PRO 1000 120V (COMBO ONLY)
1 050323 CHS ASSY ROC PRO 1000 120V HD (HEAD ONLY)
1 021709 BUSHING SR .437X.062X13/32 BLK (@ SPEAKER CABLE)
1 026038 BUSHING SR .625X.062X37/64 BLK (@ POWER CABLE 100V/120V)
1 010401 BUSHING SR .625X.125X37/64WHT 230V (@ POWER CABLE 230V)
1 026116 BUSHING SR .500X.063X7/16 BLK (@ REVERB CABLE)
1 026527 CABLE ASSY POWER W/.187 TABS (PWR CABLE 100V/120V ONLY)
1 026528 CABLE ASSY POWER 230V W/.187 TABS (PWR CABLE 230V EXPORT)
1 036479 CABLE ASSY POWER AUST.W/.187 TABS (240V AUSTRALIA ONLY)
1 040517 CHS PERFORMER 1000
1 028560 END BELL XFMR 85W (@ POWER TRANSFORMER)
1 031726 HEATSINK BAR M-80 (COUPLER TO CHASSIS)
12 019798 KNOB ROTARY SS
4 028591 NUT ACORN 8-32 (TRANSFORMER MOUNT)
1 050271 PANEL FRONT ROC PRO 1000 (COMBO & HEAD)
1 050272 PANEL REAR ROC PRO 1000 (COMBO ONLY)
1 050376 PANEL REAR ROC PRO 1000 HD (HEAD ONLY)
1 028937 SCRW TF 6-32X5/8 PHP ZI ROLOK (PCB TO CHASSIS MOUNT)
1 038900 SCRW TF 6-32X1/4 PHP ZI (GROUND LUG MOUNT)
5 028500 SCRW TF 8-32X3/4 HWH SLTD ZI (CHASSIS TO HEATSINK MOUNT)
1 025936 STAND OFF PCB PUSH ON NY 3/8L (PCB MOUNT)
1 025935 SWITCH POWER DPST (DOMESTIC ONLY)
1 039287 SWITCH POWER DPST .187 TAB GLOBAL (EXPORT ONLY)
1 026401 WSHR SHLDR FIB 3/8X5/8 (@ EXTERNAL SPEAKER JACK)
1 027520 WSHR FLAT .380X.630 FIBER (@ EXTERNAL SPEAKER JACK)
1 029894 WSHR LCK INTL 3/8X.500X.022 NI (@ EXTERNAL SPEAKER JACK)
4 030007 WSHR LCK INTL 8X.330X.02 ZI (TRANSFORMER MOUNT)
1 027668 XFMR PWR 120V 85A (120V DOMESTIC ONLY)
1 039357 XFMR PWR EXP 230V (100V/230V EXPORT ONLY)
