Fender ROC PRO 1000 - Page 5

PARTS LIST
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 040025 CAB ASSY STAGE 112SE (COMPLETE COMBO STYLE CABINET)
1 050297 CAB ASSY ROC PRO 1000 HD (COMPLETE HEAD STYLE CABINET)
1 022491 CLAMP CABLE NYL SCRW MNT 5/16 (@ REVERB CABLE)
4 026566 CORNER 2 HOLE W/TAB NI (TOP REAR & BOTTOM FRONT)
2 026568 CORNER 3 HOLE NI (BOTTOM REAR)
4 029821 EYELET RFLNGD .215 OD X.315 L (@ REVERB PAN)
4 019276 GLIDE CABINET (STEEL ONLY)
4 019275 GLIDE CUSHION INSERT (RUBBER ONLY)
1 050334 GRILLE ROC PRO 1000 COMBO (COMPLETE GRILLE)
1 050336 GRILLE ROC PRO 1000 HEAD (COMPLETE GRILLE)
1 027846 HANDLE 9.25" NO LOGO (RUBBER ONLY. NO INSERT)
1 032524 INSERT HANDLE (SPRING STEEL)
2 019279 HANDLE CAP 2-3/16 NI (HANDLE MOUNT)
1 047600 NAMEPLATE LOGO BLACK
4 050311 NUT 2-56 NYLON INSERT 2CNME-2 (NAMEPLATE LOGO MOUNT)
8 021972 NUT T 10-32X3/4 STR 3 PRNG BLX (HANDLE/SPEAKER MOUNT)
1 028055 REVERB UNIT 800Ω 8EB2C1B DN
10 026571 SCRW CORNER MOUNTING
4 050312 SCRW 2-56X3/8 FHP NI (NAMEPLETE LOGO MOUNT)
6 036199 SCRW M 8-32X1-3/16 OHP BLX WX (CHASSIS MOUNT)
5 029828 SCRW PB 8X3/4 PHP ZI (REVERB PAN/CABLE CLAMP MNT)
4 026625 SCRW WOOD 8X1 FH (GLIDE MOUNT)
6 011678 SCRW SMA 8X1-1/2 OHP BLX (GRILLE MOUNTING)
4 026577 SCRW M 10-32X1 PHP BLX (SPEAKER MOUNT)
4 022244 SCRW M 10-32X1-1/8 OHP NI (HANDLE MOUNT)
1 040598 SPEAKER 12" 8 OHM 80 WATTS
6 050317 STANDOFF RUBBER .75 DIA.X .77 (GRILLE MOUNTING)
1.061 026570 VINYL BLACK LT WEIGHT
12 029527 WSHR FNSH 8-5/8FLNGO BLX WX (CHASSIS / GRILLE MOUNT)
PARTS LIST
FOOTSWITCH ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 040409 FTSW ASSY 3 BTTN CH/GA/RV (COMPLETE FOOTSWITCH)
1 028895 CABLE ASSY FTSW RT ANG 12' (FOOTSWITCH CABLE)
2 006260 DIODE 1N4448 SIGNAL BENT CR2,3
3 031017 DIODE ZENER 1N5223B 2.7V 5% CR1,4,5
1 028109 HSG END CUP LEFT FTSW
1 028143 HSG END CUP RIGHT FTSW
1 028141 HSG FTSW 3 BUTTON
1 037036 JACK PHONE PCB MONO CA PREMIUM J1
3 031871 LED BI-COLOR 5mmX5mm LD1,2,3
1 040514 PCB ASSY FTSW 3 BTTN CH/GA/RV
1 040513 PCB FAB FTSW 3 BTTN PERFORMER (RAW BOARD)
1 040408 PLATE TOP FTSW 3 BTTN CH/GA/RV
1 024952 RES CF 1/4W 100Ω 5% R1
8 028889 SCRW SMB 6X1/4 PHP
3 037722 SPACER RND NYL .120X.187X.680
3 028714 SWITCH PUSH SPDT S1,2,3
3 031899 WSHR NYL .485X.775X.150 TK
MISCELLANEOUS
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 050337 MANUAL OWNERS ROC PRO 1000
1 050338 SCHEM REDU ROC PRO 1000 W/SERV DIA
5
