Roc Pro 700 Specifications
TYPE: PR 242
PART NUMBER: 22-6876 (100V)
22-6806 (120V)
22-6866 (230V)
22-6836 (240V)
INPUT IMPEDANCE : >1 MΩ
NOMINAL LEVEL: 100mV
POWER OUTPUT: 65 W into 8Ω at 5% THD
EFFECTS LOOP: Nominal Level; Selectable +4, -7, -16 dBV
Output Impedance: 1.2 kΩ max
Input Impedance: 100 kΩ
POWER REQUIREMENTS: 100V AC, 50/60 Hz, 200W
120V AC, 60 Hz, 200W
230V AC, 50 Hz, 200W
240V AC, 50 Hz, 200W
SPEAKER: 8Ω 12” Fender Special Design (P/N 025923)
FOOTSWITCH: 2 Button Footswitch, Controls Gain and Reverb On/Off
DIMENSIONS: Height: 16.5 in 41.9 cm
Width: 20.5 in 52.0 cm
Depth: 9.75 in 24.7 cm
Weight: 30 lbs 13.6 kg
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
NO USER SERVICEABLE PARTS INSIDE,
REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
THIS UNIT MUST BE EARTH GROUNDED.
THIS EQUIPMENT CONFORMS TO
THE FOLLOWING DIRECTIVES :
EMC 89/336/EEC AND LV 73/23/EEC
10
