TYPE: PR 499
PART NUMBER: (120 V, 60 Hz) US 023-1504-000
(110 V, 60 Hz) TW 023-1514-900
(240 V, 50 Hz) AUS 023-1534-900
(230 V, 50 Hz) UK 023-1544-900
(220 V, 50 Hz) ARG 023-1554-900
(230 V, 50 Hz) EUR 023-1564-900
(100 V, 50 Hz) JPN 023-1574-900
(220 V, 60 Hz) ROK 023-1594-900
POWER REQUIREMENTS: 75 W
POWER OUTPUT (@ 1kHz): 25 W R.M.S. at < 2.5% THD
20 W R.M.S. at < .02% THD at onset of limiter
RATED LOAD IMPEDANCE: 8 Ω
INPUT IMPEDANCE INPUT 1: 202 k Ω
INPUT 2: 120 k Ω
CD IN: 100 k Ω
FULL POWER SENSITIVITY INPUT 1: 10 mV
(all knobs max, 1 kHz) INPUT 2: 20 mV
POWER AMP IN: 270 mV
CD IN: 400 mV
EQUALIZATION RANGE BASS : ±15 dB at 40 Hz
MID: ±15 dB at 630 Hz
TREBLE: ±15 dB at 8 kHz
EFFECTS LOOP SEND IMPEDANCE: 1 k Ω
RETURN IMPEDANCE: 18 k Ω
SPEAKER COMPLEMENT: One 8 Ω Special Design 10" speaker
DIMENSIONS HEIGHT: 17.5 in (44.6 cm)
WIDTH: 15.0 in (38.3 cm)
DEPTH: 10.25 in (26.1 cm)
WEIGHT: 32 lb (14.5 kg)
Product specifications are subject to change without notice.
2315400910
2315401910
2315403910
2315404910
2315405910
2315406910
2315407910
2315409910
