SPECIFICATIONS FOR THE SRM 6302
DESIGNATION TYPE PR 332
PART NUMBER 071-6321-000 (120 V)
071-6321-030 (240 V) Aust
071-6321-040 (230 V) UK
071-6321-060 (230 V) Euro
POWER SPECIFICATIONS 120V version: 120V AC, 60 Hz, 900W
230V version: 230V AC, 50 Hz, 900W
240V version: 240V AC, 50 Hz, 900W
PRE-AMPLIFIER SECTION
MIC INPUT IMPEDANCE 1.8 kΩ
LINE INPUT IMPEDANCE 18.2 kΩ
MIC INPUT SENSITIVITY 7 mV
LINE INPUT SENSITIVITY 65 mV
CHANNEL TONE CONTROLS Low +/- 15 dB @ 30 Hz
Mid +/- 15 dB @ 750 Hz
High +/- 15 dB @ 15 kHz
GRAPHIC EQUALIZER +/- 12 dB @ 63, 125, 250, 500, 1 k, 2 k, 4 k, 8 k and 16 kHz
OVERALL AMPLIFIER -3 dB @ 10 Hz to -3 dB @ 50 kHz
FREQUENCY RESPONSE (Line In @ 10 mV)
PHANTOM POWER +46.5 V DC
POWER AMPLIFIER SECTION
POWER OUTPUT 150W per channel, <0.05% T.H.D. + noise @ 1 kHz into 4 Ω
RATED LOAD IMPEDANCE 4 Ω
INPUT SENSITIVITY 1.25 V R.M.S.
INPUT IMPEDANCE 22 kΩ
DELTACOMP
™
RANGE 20 dB
DIMENSIONS Height: 12 in 30.5 cm
Width: 21 in 53.3 cm
Depth: 11.75 in 29.8 cm
Weight: 35 lbs 15.9 kg
PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
THIS EQUIPMENT CONFORMS TO
THE FOLLOWING DIRECTIVES :
EMC 89/336/EEC AND LV 73/23/EEC
