STAGE 100/160
PARTS LIST
END ITEM ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 040071000 CAB ASSY ULT. CHORUS/STAGE 160 STAGE 160
1 040025000 CAB ASSY STAGE 100/112SE/RP1000 STAGE 100
4 023513000 CASTER SWIVEL
STAGE 160 ONLY
1 054236000 CHS ASSY STAGE 100 AMP 120V STAGE 100
1 054237000 CHS ASSY STAGE 100 AMP 230V STAGE 100
1 054238000 CHS ASSY STAGE 100 AMP 230V U.K. STAGE 100
1 054239000 CHS ASSY STAGE 100 AMP 240V AUST STAGE 100
1 054240000 CHS ASSY STAGE 100 AMP 100V STAGE 100
1 054241000 CHS ASSY STAGE 160 AMP 120V STAGE 160
1 054242000 CHS ASSY STAGE 160 AMP 230V STAGE 160
1 054243000 CHS ASSY STAGE 160 AMP 230V U.K. STAGE 160
1 054244000 CHS ASSY STAGE 160 AMP 240V AUST STAGE 160
1 054245000 CHS ASSY STAGE 160 AMP 100V STAGE 160
1 047248000 CORD PWR W/IEC CONN DOM DOMESTIC
1 047250000 CORD PWR W/IEC CONN 240V 240V AUST
1 047249000 CORD PWR W/IEC CONN 230V UK 230V U.K.
1 047251000 CORD PWR W/IEC CONN 230V 230V EUR
1 053997000 CORD PWR W/IEC CONN 100V JPN 100V JPN
1 050419000 FOOTSWITCH 2 BTN CH DRV/MDRV
1 028095000 CABLE ASSY FTSW RT ANG 12' @ FOOTSWITCH
1 040024000 GRILLE ASSY STAGE 100/112SE
STAGE 100 ONLY
1 029906000 NAMEPLATE FENDER GENERIC SMALL
1 028055000 REVERB UNIT 800 ohm 8EB2C1B DN
1 022491000 CLAMP CABLE NYL SCRW MNT 5/16 @ REV CABLE
4 029821000 EYELET RFLNGD .215 OD x.315 L @ REV PAN
5 029828000 SCRW PB 8x3/4 PHP ZI @ PAN/CLAMP
1 022327000 WSHR FLAT 8X7/16 NI @ CLAMP
2 018113000 SCRW SMA 4x1/2 OHP BLX @ LOGO
6 029527000 WSHR FNSH 8-5/8 FLNGD BLX WX @ CHS SCREWS
6 036199000 SCRW M 8-32x1-3/16 OHP BLX CP CHS SCREWS
8 026577000 SCRW M 10-32X1 PHP BLX @ SPEAKERS (4 IN STAGE 100)
2 054420000
SPKR 12" 8Ω G12T-100 CELESTION
(1 IN STAGE 100)
