SUPER CHAMP
®
XD
(This is the model name for warranty claims)
3
SPECIFICATIONS
Model Name: SUPER CHAMP XD
Release Number: PR 737
Part Numbers (120V, 60Hz) US: 2331100000
(240V, 50Hz) AUS: 2331103900
(230V, 50Hz) UK: 2331104900
(230V, 50Hz) EUR: 2331106900
(100V, 50Hz) JPN: 2331107900
Power Requirement: 90 W
Power Output: 20 W RMS into 8 ohms @ 5 %THD
Power Amp Sensitivity: 50mV for 20 W into 8 ohms @ 5 %THD
Impedances Input (Pre-Amp): >1M Ohms
Line Out: 1 kOhm
Speaker Complement: Fender Special Design, 8 ohm, 10”
(P/N 0073858000)
Dimensions Height: 15.0 in ( 38 cm)
Width: 17.5 in ( 45 cm)
Depth: 9.0 in ( 22.9 cm)
Weight: 24 lbs (10.9 kg)
Product specifications are subject to change without notice
