SUPER CHAMP
®
XD
(This is the model name for warranty claims)
7
.PARTS LIST: MAIN PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
4 0050687000 CABLE JMPR 6 CKT .156 ROUND PW1A PW1B PW2A PW2B
2 0054817000 CABLE RIBBON 4 CKT 3" P15 P17
2 0051410000 CABLE RIBBON 8 CKT 16" PW3A PW3B
4 0038692000 CAP AE AX 10uF 35V 20% C27 C45-46 C56
3 0038690000 CAP AE AX 1uF 100V 20% C12 C28 C42
1 0009521001 CAP AE AX 22uF 25V 20% C8
2 0028494000 CAP AE RDL 1000uF 35V 20% C57 C60
2 0028476003 CAP AE RDL 100uF 50V 20% C16-17
3 0054204000 CAP AE RDL 22uF 450V 20% 85'C C38 C40-41
1 0055992000 CAP AE RDL 4700uF 16V 20% 85'C C53
2 0028471003 CAP AE RDL 47uF 50V 20% C59 C62
2 0039270001 CAP CA .01uF 50V C4 C11
1 0038703001 CAP CA .1uF 50V C64
1 0039263001 CAP CA 1000pF 50V LL C14
2 0039259001 CAP CA 220pF 100V LL C2 C65
1 0039267001 CAP CA 3900pF 100V C15
2 0051457003 CAP CD 100pF 500V 5% C13 C25
5 0051406003 CAP CD 220pF 500V 10% C1 C3 C24 C26 C29
2 0051458003 CAP CD 470pF 500V 10% C21 C43
16 0034788003 CAP CR .1uF 50V 20% .2" LS
C9-10 C18-19 C22-23 C34-35 C39 C47-51 C54-55
1 0027255003 CAP MPF .001uF 100V 10% C7
1 0027270003 CAP MPF .033uF 100V 10% C37
1 0053860000 **CAP MPF .1uF 250VAC 20% C58
2 0027278003 CAP MPF .1uF 63V 10% C52 C63
1 0024833000 CAP MPF RDL .022uF 400V 10% C20
3 0024855000 CAP MPF RDL .1uF 630V 10% C5-6 C61
6 0033578003 CAP PFF RDL .001uF 100V 10% C30-33 C36 C44
6 0027941000 CONTROL SNAPIN 50k B TAPER R80-85
9 0064089001 DIODE 1N4003 D3, D26-30 D32-33 D36
6 0026730001 DIODE 1N4006 800V 1A D7-8 D12-15
13 0006260001 DIODE 1N4448 SIGNAL LL D4-6 D10-11 D18-25
2 0029690001 DIODE HV 3kV 200mA D1-2
1 0031017001 DIODE ZEN 1N5223B 2.7V 5% LL D17
1 0027327001 DIODE ZEN 1N5234B 6.2V 5% LL D9
1 0029898001 DIODE ZEN 1N5236B 7.5V 5% LL D16
2 0047140060 DIODE ZEN 1N5349B 12V 5W 5% D34-35
2 0063204000 ENCODER 16-POS 4-BIT GRAY CODE S2-3
8 0026000001 FSTN TAB MALE .187x.032 PCB MT P1-4 P6-8 P18
10 0025802000 FSTN TAB MALE .250x.032 PCB MT P9-14 P16 P19-21
2 0073586000 FUSE PICO 1A F4-5
1 0075607000 FUSE PICO 2A F3
1 0070334001 FUSE PICO 7 AMP 125V F2
1 0057191000 HDR .1 CTR 10x2 CKT SQ PIN P5
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + * Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
