GENERAL INFORMATION
Operator's Manual Combines FENDT 5275 C-6335 C- EN - LA327317011 - 09/2011 1-5
Combine identification
Fig. 4
Combine type and serial number appear on the
plate and are also punched into the rear right-hand
side of the frame (1).
Engine Identification
Fig. 5
The engine is identified by the type plate (1) in the
middle of the cylinder block.
The following information appears on the plate (1):
• Engine manufacturer
•Engine type
• Engine power and rated speed
• Engine serial number
• Valve clearance
• Customer reference code
• Idling speed
• Compliance with Directive 97/68/EC
• Name of the engine assembler.
The engine serial number is always also stamped
on the cylinder block.
Cutting table identification
Fig. 6
The cutting table is identified by a metal plate
positioned on the left-hand side of the table body
above the drive shaft, or on the left-hand side.
