SAFETY
FIG. 45: Lift location (19)
FIG. 46: Twine routing and tension into knotter area (20)
Adjust twine tension to 50 N to 70 N (12 lbf to 15 lbf).
FIG. 47: Twine routing through upper tensioners, upper
slacker arms and tucker arms (21)
FIG. 45
516931D1
19
FIG. 46
700728732
20
FIG. 47
700721970
