Ferax 16 DB - Dansk; Specifikationer

28
INDHOLDSFORTEGNELSE
Specifikationer .........................................................28
Generelle
sikkerhedsanvisninger
for
værktøjsmaskine
......................................................
29
Ekstra
sikkerhedsanvisninger for
støtteboremaskine
....................................................29
Motorspecifikationer og elektrisk krav ....................31
Forberedelser ............................................................32
DANSK
Oversættelse af den originale brugsanvisning
Vedligeholdelse ........................................................32
Smøring ....................................................................32
Anvendelse
af Lasersystemet ......................................
32..................................................................................
Fejlsøgning ...............................................................33
Koblingsskema
.........................................................34
Reservedele ..............................................................85
EG certifikat om overenstemmelse ..........................89
SPECIFIKATIONER
Art.nr.
.......................................................................................................
14798 -0106 -0205 -0304 -0403
Race
.........................................................................................................................
16 DB 16 DF 20 DB 20 DF
Model
......................................................................................................................
Bænk Støtte Bænk Støtte
Udførelse
.................................................................................................................
Manuel Manuel Manuel Manuel
Borekapacitet i stål
...............................................................................................
16 16 20 20
Spindelkonus
..................................................................................................MK 2 2 2 2
Spindelbevægelse
.........................................................................................
mm 80 80 80 80
Spindelhastighed
...............................................................................................
st 12 12 12 12
Spindelhastighed
........................................................................................
r/min 180-2740 180-2740 180-2740 180-2740
Støttens diameter
..........................................................................................
mm 70 70 70 70
Afstand spindelcentrum-støtte
.................................................................
mm 170 170 195 195
Max. afstand spindelspids-bord
...............................................................
mm 465 770 340 735
Min. afstand spindelspids-bord
................................................................mm 103 103 101 101
Bordsstørrelse
................................................................................................
mm 300 300 305x305 305x305
T-spors bredde
...............................................................................................
mm 15 15 15 15
T-spors c/c
.......................................................................................................
mm - - 140 140
Max. afstand spindelspids-grundplade
..................................................
mm 710 1260 635 1235
Bearbejdet grundplade
................................................................................
mm 200x200 200x200 200x200 200x200
T-spors bredde
...............................................................................................
mm 15 15 15 15
T-spors
c/c
.......................................................................................................
mm 130 130 130 130
Motorspænding
..................................................................................................V 230 1-fase 230 1-fase 230 1-fase 230 1-fase
.....................................................................................................................................
50 Hz 50 Hz 50 Hz 50 Hz
Motoreffekt
.....................................................................................................
kW 0,55 0,55 0,55 0,55
Højde
.................................................................................................................
mm 1065 1610 1065 1635
Vægt
.....................................................................................................................
kg 51 57 55 63
