Ferax 16 DB - English; Specifications

42
TABLE OF CONTENTS
Specifications ........................................................... 42
General safety instructions for machine
tools ......... 43
Extra safety instructions for
pillar drilling machines ............................................ 43
Motor specifications and electrical
requirements ............................................................. 45
Preparations .............................................................. 46
English
Original instructions
Maintenance ............................................................. 46
Lubrication ............................................................... 46
Using the Laser system ............................................
46
Troubleshooting ....................................................... 47
Wiring diagram ........................................................ 48
Spare parts .................................................................85
EC- Declaration of conformity .................................89
SPECIFICATIONS
Art. no.
...........................................................................................
14798 -0106 -0205 -0304 -0403
Race
..............................................................................................................
16 DB 16 DF 20
DB 20 DF
Model .
..........................................................................................................
Bench Pillar Bench Pillar
Design
............................................................................................................
Manual Manual Manual Manual
Drilling capacity in steel
........................................................................
16 16 20 20
Spindle crown
.....................................................................................
MK 2 2 2 2
Spindle movement
.............................................................................
mm 80 80 80 80
Spindle speed
.....................................................................................
unit 12 12 12 12
Spindle
speed
......................................................................................
rpm 180-2740 180-2740 180-2740 180-2740
Pillar diameter
..................................................................................... mm 70 70 70 70
Distance spindle centre-pillar
........................................................
mm 170 170 195 195
Max. distance spindle nose-table
.................................................
mm 465 770 340 735
Min. distance spindle nose-table
..................................................
mm 103 103 101 101
Table size
............................................................................................
mm 300 300 305x305 305x305
T
slot
width
..........................................................................................
mm 15 15 15 15
T slot c/c
...............................................................................................
mm - - 140 140
Max. distance spindle nose-base plate
.......................................
mm 710 1260 635 1235
Machined base plate
.........................................................................
mm 200x200 200x200 200x200 200x200
T slot width
........................................................................................
mm 15 15 15 15
T
slot c/c
...............................................................................................
mm 130 130 130 130
Motor voltage
..........................................................................................
V 230 1-phase 230 1-phase
230 1-phase 230 trijų
..........................................................................................................................
50 Hz 50 Hz 50 Hz phase 50 Hz
Motor output
........................................................................................
kW 0,55 0,55 0,55 0,55
Height
....................................................................................................
mm 1065 1610 1065 1635
Weight
......................................................................................................kg 51 57 55 63
