Ferax 16 DB - Page 87

87
No.
Description
Drawing code
Qty
1 Base 16101001A 1
2 Support-Column 16101002(F)
16101002B(B) 1
3 Screw-Hex HD GB5781-86 M10*40 1
4 Screw-Hex Soc Set GB80-85 M10*12 1
5 Rack 16101010(F)
16101010A(B) 1
6 Crank 13201009 1
7 Screw-Hex Soc Set GB80-85 M6*10 2
8 Table-Column 16101003(F)
16101003B(B) 1
9 Support-Table w/
Indicator 16101004 1
10 Collar-Rack 16101011D 1
11 Worm 16101008 1
12 Diagonal-Gear-Pivot 16101006 1
13 Pin-Table Support
Lock 16101012A 1
15 Pin 16101007 1
16 Table-Drill Press w/
Scale 16101014H 1
17 Screw-Hex HD GB5781-86 M16*35 1
18 Table Arm 16101005 1
19 Pin-Table Arm Lock 16101013A 1
21 Fence Clampinig 16108003-1 1
22 Wing Nut GB62-88 M6 1
23 Wisher GB96-85/ 10 2
24 Lock-Knob-
Components 16108003-2 2
25 Cup Head Bolt GB12-88 M6*16 1
26 Side Fence 16108003-4 1
27 Gliding Nut 16108003-3 1
28 Lock-Nut M20*1.5 16103005 1
29 Locking Ring 16103004 1
30 Washer 16103003 1
31 Ball Bearing GB276-89/ 60203 1
32 Rubber Washer 16103006 1
33 Quill 16103002 1
34 Wedge Drift 16103008 1
35 Collar 16108005-1 1
36 Hex.Nut GB6172-86 M10 2
37 Chuck 16103009H 1
38 Chuck Key
39 Arbor 16103007A 1
40 Spindle 16103001 1
41 Ball Bearing GB276-89 80204 1
42 Self Tapping Screw GB845-85 ST4.2*9.5 4
43 Switch 16102010N 1
44 Pan Hd Screw GB818-85 M5*16 3
45 Wire Terminal CE-5 1
46 Light Switch 16102012C 1
47 Switch Box 16102008C 1
48 Pan Hd Screw GB818-85 M5*6
2
49 Lockwasher GB862.1-87/5 2
50 Special Screw Set 16102021 1
51 Hex.Nut GB6172-86 M12 2
52 Sping Cap 16104008 1
53 Quill Sping 16104009 1
54 Sping Cover 16104007A 1
55 Depth Stop Thread
Assem. 16108005 1
56 Plug & Cable DLCABB3G14 1
57 Allen Key GB5356-86 S3 S4 1
58 Allen Key GB5356-86 S5 S6 1
59 Pan Hd Screw GB818-85 M5*10 2
60 Cable Socket 16102014A 1
61 Hex.Hd Screw GB5781-86 M8*16 1
62 Adjusting Lever 16102006 1
63 Motor YLL7124B-T 1
64 Hex.Nut GB6170-86 M8 4
65 Washer GB67.2-85/8 1
66 Motor Cable 16102016G 2
67 Hex.Nut GB6170-86 M12 2
68 Lockwasher GB93-87/ 12 1
69 Motor Mounting
Plate 16102007A 8
70 Hex. Bolt GB5781-86 M8*16 4
71 Motor Bracket
Support -A 16102003 1
72 Motor Bracket
Support -B 16102002 1
73 Circlip GB894.1-86/ 15 1
74 Roll Pin GB879-86 6*25 2
75 Belt Tention Lock
Knob 1601013A 2
76 Belt Tention Lever 16102004 1
77 Leaser Beam 13302026 2
78 Transformer 13A105006/DQ053001100 1
79 Head w/Pointer&Trim 16102001T 1
80 Depth Stop Collar/
w/Scale 16104003C 1
81 Hub Assm. 16104002B 1
82 Roll Pin GB879-86 6*45 1
83 Iron Knob 16104001C 1
84 Cylindric Screw-Hex
Soc Set GB70-86 M8*30 1
85 Wire 16102018B 1
86 Retaining Ring 16102024 2
87 Ball Bearing 16102023A 1
88 Pulley Insert 13302022 1
89 Pulley Insert 16102022 1
90 Pulley Spindle 16105009J 1
91 Pulley Nut 16102025 1
92 “V” Belt A33 16105011 1
93 Knob 16105008D 1
94 Belt A 29 16805010 1
95 Ball Bearing GB276-89/ 60202 2
20 DB / DF part list
