4
EN
CORDLESS DRILL
CDM1104
Thank you for buying this Ferm product.
By doing so you now have an excellent product,
delivered by one of Europe’s leading suppliers.
All products delivered to you by Ferm are
manufactured according to the highest standards
of performance and safety. As part of our
philosophy we also provide an excellent customer
service, backed by our comprehensive warranty.
We hope you will enjoy using this product for
many years to come.
The numbers in the text refer to the diagrams
on pages 2 - 3.
Read the operating instructions carefully
before using this device. Familiarise
yourself with its functions and basic
operation. Service the device as per the
instructions to ensure that it always
functions properly. The operating
instructions and the accompanying
documentation must be kept in the
vicinity of the device.
Contents
1. Machine information
2. Safety instructions
3. Mounting accessories
4. Operation
5. Service & maintenance
1. MACHINE INFORMATION
7HFKQLFDOVSHFL¿FDWLRQV
Voltage 12 V
Charger voltage 230 V
Charger frequency 50 Hz
Battery output 1.3 Ah
Charging time 3-5 hours
Max. torque (low speed) 10 Nm
No-load speed 0 - 550/min
Chuck capacity 0.8 - 10 mm
Weight (incl. battery) 2.0 kg
Lpa (acoustic pressure) 63 + 3 dB(A)
Lwa (acoustic power) 74 + 3 dB(A)
Vibration value
When drilling in metal 2.083 + 1.5 m/s
2
Screwdriving 2.174 + 1.5 m/s
2
Vibration level
The vibration emission level stated in this instruction
manual has been measured in accordance with a
standardised test given in EN 60745; it may be used
to compare one tool with another and as a
preliminary assessment of exposure to vibration
when using the tool for the applications mentioned
- using the tool for different applications, or with
different or poorly maintainted accessories,
PD\VLJQL¿FDQWO\LQFUHDVHWKHH[SRVXUHOHYHO
- the times when the tool is switched off or when
it is running but not actually doing the job, may
VLJQL¿FDQWO\UHGXFHWKHH[SRVXUHOHYHO
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns
Contents of packing
1 Cordless drill
2 Batteries
1 Adapter + battery holder
2 Double-sides bits
1 Operating instructions
1 Safety instructions
1 Warranty card
Check the appliance, any loose parts and
accessories for damage caused during transport
Product information
Fig. A
1. On/off switch
2. Torque setting ring
3. Chuck
4. Battery
5. Direction switch
2. SAFETY INSTRUCTIONS
([SODQDWLRQRIWKHV\PEROV
DESCRIPTION (FIG. A)
Denotes risk of personal injury, loss of
life or damage to the tool in case of
non-observance of the instructions in
this manual.
Indicates electrical shock hazard.
