• Switchoffthetoolandwaituntilthebladehas
stopped completely before moving the saw
away from the work or putting it down. Hearing
protection should be worn when using circular
saw.
Switch off the machine immediately when you
discover:
• Adefectivemainsplugormainslead;
• Adefectiveswitch.
• Overheatingofthecircularsaw.
• Smokeorodeurcausedbyscorched
insulation.
Electrical safety
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions. Keep these
instructions in a safe place!
Alwayscheckthatthepowersupply
corresponds to the voltage on the rating
plate.
Class II machine – Double insulation –
You don’t need any earthed plug.
Replacing cables or plugs
If the mains cable becomes damaged, it must
be replaced with a special mains cable available
from the manufacturer or the manufacturer’s
customer service. Dispose of old cables or plugs
immediately after replacing them with new ones. It
is dangerous to connect the plug of a loose cable
to a socket.
Using extension cables
Only use an approved extension cable suitable
for the power input of the machine. The minimum
conductor size is 1.5 mm2. When using a cable
reel always unwind the reel completely.
3. ASSEMBLY AND ADJUSTING
INSTRUCTIONS
Before adjusting the saw, make sure the
plug is removed from the socket.
Setting the sawing angle (bevel)
• Loosenbothknobs(12).
• Rotatethesoleplatetothecorrectposition(0°
-45°),andtightentheknobs.Thesawingangle
(bevel) can be read on the protractor (14).
Fitting the ripfence
• Loosenknob(11).
• Inserttheripfenceintotheslotsprovided.
• Setthecorrectcutwidthandtightentheknob
(11).
Setting the cutting depth
• Loosenknob(3).
• Movethesoleplate(7)downwards.
• Thecutdepthofthesawbladecanbereadoff
on the side of the safety guard.
• Tightentheclampingknob(3)oncethecorrect
depth is set.
Exchanging or cleaning the saw blade
• Usetheshaftlockingknob(13)topreventthe
shaft from rotating.
• Nextloosenthehexagonscrew(6)inthe
centre of the saw blade, using the Allen key
provided.
• Turnthesafetyguardtotherear,andholdit
there with the aid of the knob (15).
• Withdrawtheretainingringandthesawblade,
and clean the saw blade, or replace it with a
new one.
• Againplacethesawbladebackontheshaft.
• Allowthesafetyguardtoreturnoverthesaw
blade by releasing the knob (15).
• Presstheshaftlockingknob(13)backin,refit
the retaining ring (8) and tighten the hexagon
screw (6) firmly once more.
