Ferm CSM1039 - Page 68

68
Spare parts list
CSM1039
No Description Position
300755 Switch 5
402609 Carbon brush set 15
402618 Carbon brush cap 16
300796 Stator 18..20
300795 Rotor 25
300758 Flange set complete 29, 41, 43
CSA1003 Carbon tipped saw blade, 180mm 42
CSA1007 Saw blade circular saw, 185mm 42
300813 Big gear 56
300759 Baseplate complete 37, 64..69
300760 Parallel guide 70
470183 Left handle 8
470184 Phill pan head screw M5x22 10
470185 Phill pan head screw M5x60 12
470186 Brush holder 14
470187 Deflector + Screws 21, 22
470189 Hexagon screw 32
470190 Phill pan head screw M4x22 34
470191 Depth scale+special nut M6 36..39
403999 Powerplug + 3m rubber cable 6
480582 Bearing 26, 27
480583 Dust oulet 30
