Description
The numbers in the text refer to the diagrams on
pages 2-3
Fig. A
1. On/off switch
3. Hammer selection lever
4. Chuck
5. Locking sleeve
6. Main grip
7. Auxiliary grip
8. Carbon brush cover
9. Lubrication point
3. ASSEMBLY
Before assembly, always switch off the
machine and remove the mains plug
from the mains.
Mounting and removing the accessory
Fig. B
Do not use blunt drill bits or chisels.
Immediately sharpen or replace blunt
drill bits or chisels.
Mounting
accessory.
counterclockwise until it locks into place.
Removing
Mounting and removing the auxiliary grip
Fig. C
Mounting
counterclockwise.
chuck (4).
position.
clockwise.
Removing
counterclockwise.
clockwise.
Mounting and removing the dust collector
Fig. D
The dust collector prevents dust from entering the
machine when drilling into ceilings.
Immediately replace a damaged dust
collector.
Mounting
chuck (4).
the accessory.
(15) into the chuck (4).
Removing
(15) from the chuck (4).
accessory.
4. USE
Switching on and off
Fig. A
switch (1).
switch (1).
Setting the operating mode
Fig. A & E
The drill selection switch and the hammer
selection lever must be set according to the
required operating mode. Refer to the table below
to set the required operating mode.
Setting Operating mode
Fig. E
B Hammer drill
hammer selection lever (3) to the required
position.
Hints for optimum use
for small workpieces.
machine. Let the machine do the work.
machine to come to a complete standstill
before putting the machine down.
5. CLEANING AND
MAINTENANCE
Before cleaning and maintenance, always
switch off the machine and remove the
mains plug from the mains.
Clean the machine casings regularly with a soft
cloth, preferably after each use. Make sure that
the ventilation openings are free of dust and
dirt. Remove very persistent dirt using a soft
solvents such as gasoline, alcohol, ammonia
etc. Chemicals such as these will damage the
synthetic components.
Checking and replacing the carbon brushes
Fig. A
The carbon brushes must be checked regularly.
If the carbon brushes are worn, the machine will
start to run unevenly.
Only use the correct type of carbon
brushes.
screwdriver.
