Mains plug replacement (UK only)
If the moulded 3-pin plug attached to the unit is
damaged and needs replacing, it is important
that it is correctly destroyed and replaced by
an approved BS1363/13A fused plug and that
the following wiring instructions are followed.
The wires in the mains cable are coloured in
accordance with the following code:
As the colours of the wires in the mains cable
of the unit may not correspond to the coloured
markings identifying the terminals in the plug,
proceed as follows:
connected to the terminal which is marked
with the letter N or coloured black.
connected to the terminal which is marked
with the letter L or coloured red.
Use of extension leads
Only ever use approved extension leads that are
suitable for the power rating of the machine. The
minimum core thickness is 1.5 mm
2
. Whenever
using a reel extension lead, always fully unroll the
lead.
Immediately switch off the machine when:
mains lead damage.
2. MACHINE INFORMATION
Intended use
This rotary hammer is intended for drilling holes
in masonry such as brick, concrete and similar
material. Furthermore, the machine can be used
as a demolition hammer in combination with the
account intended for other purposes.
Not suitable for construction site usage
Technical specifications
Mains voltage 230-240 V ~
Mains frequency 50 Hz
Power input 850 W
No-load speed 900 /min
Impact rate 4000 /min
Max. Drill diameter
-Concrete
-Steel
-Wood
Ø 26 mm
Ø 13 mm
Ø 40 mm
Weight 4.6 kg
Sound pressure (L
PA
)
87.9dB(A)
K=3 dB(A)
Acoustic power (L
WA
)
98.9dB(A)
K=3 dB(A)
Vibration
Hammer drilling concrete a
h
,
HD
17.812m/s
2
K=1.5m/s
2
Chiseling a
h,Cheq
16.377 m/s
2
K=1.5m/s
2
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardized test given in
EN60745. It may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned.
different or poorly maintained accessories,
may significantly increase the exposure level.
when it is running but not actually doing the
job, may significantly reduce the exposure
level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm and organizing your work
patterns.
Wear safety gloves.
Do not dispose of the product in
unsuitable containers.
The product is in accordance with the
applicable safety standards in the
European directives.
Additional safety warnings for rotary
hammers
a) Wear ear protectors. Exposure to noise can
cause hearing loss.
b) Use auxiliary handle(s), if supplied with the
tool. Loss of control can cause personal injury.
c) Hold power tool by insulated gripping
surfaces, when performing an operation
where the cutting accessory may contact
hidden wiring or its own cord. Cutting
accessory contacting a “live” wire may make
exposed metal parts of the power tool “live”
and could give the operator an electric shock.
Electrical safety
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Always check that the voltage of the
power supply corresponds to the voltage
on the rating plate label.
Class II machine - Double insulation - You
don’t need any earthed plug.
If operating a power tool in a damp location is
of electric shock.
Replacement of power cords or plugs
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
