Ferm TDM1025 - Assembly

EN
6
Ferm
Wear eye and ear protection.
During use the following points must be
considered:
• Donotremoveanymechanicalorelectrical
protective provisions.
• Checkwhetheralltheprotectiveprovisions
are in place and have been attached correctly.
• Wearsafetygogglesduringdrilling.
• Ifyouhavelonghair,besuretowearhair
protection (hair net or cap). Long hair can
easily be caught in moving parts.
• Wearfittedclothing;tiebuttonsonsleeves.
• Donotholdanyworkpiecesinyourhands
when drilling. Always use a machine clamp or
another clamping tool.
• Protectworkpiecesandclampingtoolsonthe
bench to prevent them from getting caught.
Fasten them yourself with screws or clamp
them to a machine clamp fastened to the
table.
• Checkwhetherthedrillholderistightened
properly.
• Checkwhethercablelead-throughsareokay.
• Toremovedrillchipsonlyusehandbrushes,
brushes, rubber wipers, chip hooks or similar
aids.
• Donotcarryoutanycleaningorgreasingwork
while the machine is in operation.
• AlwayskeepV-beltscovered(sothatyour
hands cannot become caught).
• Onlytightenthetoothedringdrillholderby
means of the wrench.
• Neverleavethewrenchofthedrillholderin
the drill holder! Before switching on the
machine, check whether the wrench really has
been removed!
• Donotuseanydrillswhicharedamagedon
the shank.
• Drillisnotsuitabletouseaspress!
• Ifthemainscableisdamaged,itmayonlybe
replaced by a mains cable of the same type.
Laser beam.
Never look into the light beam
Laser Class 2
from DIN EN60825-1:2007;
Ï: 650 nm; P ≤ 1mW
Additional safety warnings for lasers
• Do not look directly into the laser beam.
• Do not point the laser beam humans or
animals.
• Do not point the laser beam at strongly
reflecting material.
• Do not insert hard objects into the laser optics.
• Clean the laser optics with a soft, dry brush.
• Only have the laser repaired by a qualified
technician.
Immediately switch off the machine when:
• Interruptioninthemainsplug,mainsleador
mains lead damage.
• Defectswitch.
• Smokeorstenchofscorchedisolation.
Electrical safety
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Always check that the power supply
corresponds to the voltage on the rating
plate.
The machine is provided with a zero
voltage switch. After the tension drops
the machine will not start to run
automatically for safety reasons. The
machine must be switched on again.
Replacing cables or plugs
Immediatelythrowawayoldcablesorplugswhen
theyhavebeenreplacedbynewones.Itis
dangerous to insert the plug of a loose cable in the
wall outlet.
Using extension cables
Only use an approved extension cable suitable for
the power input of the machine. The minimum
conductor size is 1.5 mm
2
. When using a cable
reel always unwind the reel completely.
3. Assembly
Fig. B
• Placethefootplate(13)inthecorrectposition.
• Fastenthecolumn(11)withtheboltssupplied
(12) to the footplate.
• Nowslidethetableholder(10)withthetable
over the column (11). With the fastening
handle (6) the table is fastened into the
desired position.
• Nowyoucanassemblethemachinecasing
(7) and lock with the locking pins (8).
