Fermax 9449 - Technical Specifications; Operational and Physical Specifications

8 DUOX PLUS WIFI VEO XS MONITOR
TECHNICAL SPECIFICATIONS
EXTENSIONS:LightandbuzzeractivatorRef.2438


 


 







 

   
Ref. 2438
Please note: This VEO XS WIFI monitor is compatible with VEO and VEO XS monitors
with versions V2.x and V3.x.
If any of the indicated versions of monitors are replaced, the monitor connector must also
be changed. The current monitor connector has the reference 9447.
Power supply (without polarity) 18 - 24 Vdc
Consumption
Consumption at rest (matched and connected) 1.3 W
Maximum consumption 6.9 W
Maximum consumption (with induction loop) 14.4 W
Number of terminals per dwelling 3
Address of each monitor: 6 digits 000001...999999
Operating temperature [-5º , +40ºC] / [23º, 104ºF]
Humidity [0% - 90%]
OSD Screen TFT 4.3”
Resolution
Horizontal: 480LineTV
Vertical: 272 Line TV
Monitor dimensions 165 x 125 x 21 mm - 6.5” x 4.9” x 0.8”
(H x W x D)
