• Slow ash (2 blinks / 3 sec): Day or Mixed Guard Unit Mode.
• Slow ash (1 blink / 1 sec): Inverse or Sequential Programming.
See VIDEO DUOX Advanced Programming Manual cod.
970053.
• Off: Standby or Guard Unit Night Mode.
2
DL1: Mode Led:
1
CN1
Connection call extension module.
3
PRG. SW1: Programming button. MASTER Panel:
• Apartment terminals programming is always done from the
panel activated as MASTER.
• Any installation can only have one MASTER panel at a time,
whether a single or multiple block installation, once congured
as a sub-block, block or general entrance.
• A street panel is congured as a MASTER via the SW1 amplier
button. If the PRG. SW1 button is pressed 3 times quickly, it is
activated as a MASTER panel and a conrmation tone sounds
MÁSTER, after 2 seconds. It can also be congured with
a keypad code, see Section II. The panel is programmed as
master by default.
(If a panel is set as Master and any address parameter (panel
type, block number, sub-block number or panel number) is
changed, Master Mode will be disabled).
