Fermax MDS DIRECT User Manual

Pag. 13
Technical Book
MDS-ADS
MDS-ADS
TYPE C: Medium-sized Blocks.
Enter
PASOS
1
Programming mode
Enter
PASOS
1
Programming mode
Enter
PASOS
1
Programming mode
Audio-4:
Telephone 1: 0 1 0 1
Audio-4:
Telephone 2: 0 1 4 5
Audio-4:
Telephone 3: 0 0 0 0
Audio-4:
Telephone 4: F F F F
Block 1
(45 Apartments)
Audio-4:
Telephone 1: 0 2 0 1
Audio-4:
Telephone 2: 0 2 4 5
Audio-4:
Telephone 3: 0 0 0 0
Audio-4:
Telephone 4: F F F F
Block 2
(45 Apartments)
Audio-4:
Telephone 1: 0 6 0 1
Audio-4:
Telephone 2: 0 6 4 5
Audio-4:
Telephone 3: 0 0 0 0
Audio-4:
Telephone 4: F F F F
Block 6
(45 Apartments)
...................................
ADS Decoder
2
Programming
Blocks 3, 4 and 5
(programmed the same way)
Block 9
(will be programmed the same way)
Enter
STEPS
1
Programming
Enter
STEPS
1
Programming
Enter
STEPS
1
Programming
Audio-4:
Telephone 1: 0 7 0 1
Audio-4:
Telephone 2: 0 7 3 0
Audio-4:
Telephone 3: 0 0 0 0
Audio-4:
Telephone 4: F F F F
Block 7
(30 Apartments)
Audio-4:
Telephone 1: 0 8 0 1
Audio-4:
Telephone 2: 0 8 3 0
Audio-4:
Telephone 3: 0 0 0 0
Audio-4:
Telephone 4: F F F F
Block 8
(30 Apartments)
Audio-4:
Telephone 1: 1 0 0 1
Audio-4:
Telephone 2: 1 0 3 0
Audio-4:
Telephone 3: 0 0 0 0
Audio-4:
Telephone 4: F F F F
Block 10
(30 Apartments)
...................................
ADS Decoder
2
Programming
Initial address
02: Block nº
01: Initial.house nº.
Final address
02: Block nº.
45: Final. house nº.
0000 -> The monitors/te-
lephones will be
programmed from the
ADS panel.
This output is NOT to be
PROGRAMMED. Leave
in FFFF.
